sp12 12-inch full range speaker




applications

feature

outdoor

unique hdwt high density waterproof technology

all-weather

cp anticorrosive metal treatment technology

waterscape

the surface of component is waterproof with wrd waterproof adhesive

theatre

uce point sound source uniform energy cover technology

multi-function hall

odc point source directivity optimization control technology

bar

frequency response special design to avoid auditory fatigue


rotatable and asymmetrical horn


13x m8 rigging points


pole mount socket



technical specification

frequency respond

60hz ~ 18 khz (±3 db)50 hz ~ 20 khz (-10 db)

nominal coverage(-6db)

50°-100°(h)55°(v) constant directivity

sensitivity

96 db spl

powerating(aes)

400 w(continuous);1600 w(peak)

nominal impedance

8 ω

maximum spl

122 db(continuous);128 db(peak)

drivers

hf  1 x 44 mm compression driver

lf  1 x 12"(75 mm voice coil)woofer



physical data

dimension( h x w x d)

632 x 356 x 352 mm

weight

23 kg

connectors

2 x wp4 waterproof connectors

speaker cables

1-2

materials

ap acoustics professional birch plywood

finish

treatment of hdwt high density waterproof technology

grille

aluminum mesh sound-permeable waterproof mesh fabric

level of protection

ip56
