outdoor

unique hdwt high density waterproof technology.

all weather

cp anticorrosive metal treatment technology.

waterscape

the surface of component is wrd waterproof adhesive.

theatre

patented technology of cwg plane wave generator.

touring performance

spct phase correction patent technology.

stadium

large-scale,thri-amp,three-way line array system

mf & hf parts is coaxial structure to optimise acoustic image

mf & hf neodymium driver, elastic bass

frequency respond

50 hz ~ 16 khz (± 3 db)；40 hz ~ 18 khz (-10 db)

nominal coverage(-6db)

90°(h)；7.5°(v)adjustable

sensitivity

hf:110 db spl；mf:105 db spl；lf:98 db spl

powerating(aes)

hf:160 w(continuous);640 w(peak)

mf:350 w(continuous);1400 w(peak)

lf:900 w(continuous);3600 w(peak)

nominal impedance

16 ω

maximum spl

hf:132 db(continuous);138 db(peak)

mf:130 db(continuous);136 db(peak)

lf:127 db(continuous);133 db(peak)

drivers

hf: 2×3"(75 mm voice coil) driver

mf: 1×10"(65 mm voice coil)mid range

lf: 2×12"(75 mm voice coil) woofer

dimension( h x w x d)

410×1072×550 mm

weight

62 kg

connectors

2 x wp7 connectors

speaker cables

lf:1-2 ；mf:3-4 ；hf:5-6

materials

aabp composite aluminum alloy birch board box

finish

treatment of hdwt high density waterproof technology

grille

aluminum mesh sound-permeable waterproof mesh fabric

rigging

0°、1°、2°、3°、4°、5°、6°、7.5°adjustable

level of protection

ip56
