sj108s single 15-inch line array speaker




applications

feature

outdoor

unique hdwt high density waterproof technology

all-weather

cp anticorrosive metal treatment technology

waterscape

the surface of component is waterproof with wrd waterproof adhesive

theatre

using ade acoustics special cloth edge driver, thick and elastic listening

multi-function hall

75mm voice coil high-transient response woofer

church




technical specification

frequency respond

40 hz ~ 200 hz (±3 db)30 hz ~ 300 hz (-10 db)

nominal coverage(-6db)

omnidirectional

sensitivity

98 db spl

powerating(aes)

500 w(continuous);2000 w(peak)

nominal impedance

8 ω

maximum spl

125 db(continuous);131 db(peak)

drivers

1×15"(75 mm voice coil)woofer



physical data

dimension( h x w x d)

494×622×600 mm

weight

28kg

connectors

2 x  wp4 connectors

speaker cables

1-2 (lf input)

materials

aabp composite aluminum alloy birch plywood

finish

treatment of hdwt high density waterproof technology

grille

aluminum mesh sound-permeable waterproof mesh fabric

rigging

non-adjustable

level of protection

ip56
