sj208 dual 8-inch line array speaker






applications

feature

outdoor

unique hdwt high density waterproof technology.

waterscape

cp anticorrosive metal treatment technology.

theatre

the surface of component is wrd waterproof adhesive.

multi-function hall

patented technology of cwg plane wave generator.

touring performance

spct phase correction patent technology.

stadium

elastic bass.

church




technical specification

frequency respond

80 hz ~ 16 khz (±3db)70 hz ~ 18 khz (-10db)

nominal coverage(-6db)

90°(h)10°(v) adjustable

sensitivity

97 db spl

powerating(aes)

250 w(continuous);1000 w(peak)

nominal impedance

16 ω

maximum spl

121 db(continuous);127 db(peak)

drivers

hf:1×3" (75 mm voice coil) driver

lf:1×8" (50 mm voice coil) woofer



physical data

dimension( h x w x d)

305×622×360 mm

weight

23 kg

connectors

2 x wp4 connectors

speaker cables

1-2 (built-in frequency division full frequency input)

materials

aabp composite aluminum alloy birch board box

finish

treatment of hdwt high density waterproof technology

grille

aluminum mesh sound-permeable waterproof mesh fabric

rigging

0°,2°,4°,6°,8°,10° degree adjustable

level of protection

ip56
