middle and large touring performance

mf and hf coaxial structure

stadium

hifi class, low frequency elasticity, soft and

slim high frequency

presettable angles on the ground

adjustable angle with manual hoister in the

air

frequency respond

50 hz ~ 16 khz(±3 db)；40 hz ~ 18 khz(-10 db)

nominal coverage(- 6 db)

90°(h)x10°(v)

sensitivity(@1w/1m)

hf:112 db spl mf:106 db spl lf: 96 db spl

powerating(aes)

hf/mf/lf:120 /130 /800 w(aes)

nominal impedance

hf/mf/lf:16/16/16 ω

maximum spl

hf:132/138 db spl peak

mf:127/133 db spl peak

lf:125/131 db spl peak

drivers

2×10"woofer(75mm voice coil)

1×8"mid bass(38mm voice coil)

2×1.75"neodymium compression driver (44mm voice coil)

dimension( h x w x d)

303×700×496 mm

weight

35kg

speaker cables

1-2 lf 3-4 ...mf 5-6 ...hf

connectors

2 x wp7 connectors

materials

15 mm,18 mm birch multi-plywood

finish

black polyurea coatings

grille

porous steel mesh with black spraying

rigging

0、1、2、3、4、5、6、7、8、9、10° degree adjustable
