ps12—foldback loudspeaker-和记娱乐手机版下载

bar

elastic bass

ktv

long throw rubber edge lf driver

near-field sound

rotatable 80x50°directivity horn

frequency respond

55 hz ~ 18 khz(±3 db);40 hz ~ 20 khz(-10 db)

nominal coverage(- 6 db)

80°(h) 50°(v) constant directivity

sensitivity(@1w/1m)

96 db spl

powerating(aes)

450w

nominal impedance

8ohm

maximum spl

122 db (continuous) 128 db (peak)

drivers

lf: 1x12"(75 mm voice coil) rubber edge woofer

hf: 1x1.75"(44 mm voice coil) diaphragm compression

driver.

dimension( h x w x d)

602×340×350 mm

weight

22kg

connectors

2 x nl4mp neutrik speakon connectors

speaker cables

1 1-(signal input & loop)

materials

18 mm multiply-plywood

finish

black water paintings

grille

porous steel mesh with black spraying
