arcs wide | |
type | constant curvature wst enclosure |
powering and driving system | la4x, la8, la12x |
bandwidth | 55hz - 20khz ([arcs_wifo] preset) |
maximum spl | 137db ([arcs_wifo] preset) |
nominal directivity | h x v: 90° x30° |
transducers | lf: 1 × 12’’, bass reflex hf: 1 × 3’’compression |
rigging | high strength steel with anti-corrosion coating rigging rails and wiforig coupling bars |
dimension(w×h×d) | 365/140 x 759 x 444mm 14.4/5.5 x 29.9 x 17.5in |
net weight | 36kg - 79lbs |
