axle krx202


small format, high pressure powered stereo system

while the smallest of the axle line, the axle-krx202 can pack a punch. composed of one dragon-kx12 18" coaxial loudspeaker paired with a thunder-kmt18 18” subwoofer per side in a stereo configuration, the krx202 is an aggressive, small format portable system that produces high pressure in the near field.

ideal applications are dj use, small clubs and lounges, and event productions.




features


unique performance-to-size ratio

color customizable

integrated dsp

dante compatible

four-corner port configuration

selectable coverage

self-powered capabilities

onboard touch screen


applications


theatrical reinforcement

concert halls

av system

movie and special effects

religious venues

clubs

bars

yacht

restaurants

touring and fixed film and television system

theatre




specifications


rumble-kmt181

acoustics

power handling

800 w (aes)

impedance

8 ohm

frequency range

30 hz - 150 hz ± 3db (preset relating)

maximum spl

130 db continuous - 136 db peak

coverage

horizontal

omni°

vertical

omni°

crossover

coaxial

dsp controlled

frequency

150 hz (preset dependent)

transducers

full-range

1 x 18” neodymium speakers with 3” voice coil

amplifiers

type

1 modules class d - dsp controlled

power

2x1000 watt @ 8ω

protection

dynamic limiter, over current, over temp, short circuits

dragon-kx12

acoustics

power handling

800 200 w

impedance

8 ohm

frequency range

120 hz - 19 khz

maximum spl

127 db continuous - 133 db peak

coverage

horizontal

100°/30° (depending on horn orientation)

vertical

30°/100° (depending on horn orientation)

crossover

coaxial

external crossover required

frequency

12” neodymiun magnet woofer with 3” voice coil

neodymium magnet compression driver with 2”voice coil

power audio imput

connectors

2 x 4-pin speakon

wiring

1 1- (signal in & link ) 2 2- (through)

recommended amplifiers

type

kmt18, kmt21, kmt218, ka84 neodymium magnet compression driver with 2”voice coil

physical overview

dimensions

34.0 x 32.0 x 20.0 cm (13.38”x 12.59”x 7.87”) (1)

weight

12.2 kg (26.89 lb)
