input channel：dp24(2 channel)

output channel：dp24(4 channel)

input impedance:>10kω

output impedance： 50ω

max.spl： 20dbu

model：electronic balance

monitor: two line 20 character backlight lcd

electronical level: 7-bit led

the key： 6、8、9 mute button

6、8、9 channel selection button

3 menu button

3 parameter control button

master gain:-12 to 12db, 0.1db stepping

channel gain: -18 to 0 db, 0.1db stepping

phase：0°or 180°

delay: each input/output max.290ms

eq: each input/output,7xeq

eq types: peq, shelv

eq gain：-15 to 15db, 0.5db stepping

eq bandwidth: 0.009 to 4.8 octaves(q=0.3 to 20)

★analog audio

★connector

★frequency separating filter

frequency response： /- 1db (20 to 20khz)

snr：92db typical (a weighted)

cmrr: > 40db (20 to 10khz)

crosstalk：< -100db

distortion：0.005% (1khz @0dbu)

analog audio input/output: 3pin xlr

rs-485: 3 pin. m xlr.fm xlr

usb connector: type b

digital audio output connector: s/pdif

power: socket with iec standard

filter type：butterworth, bessel,

linkwitz riley

the slope: 6 to 24db/oct

★digital audio

★general specification

★rms limiter

dsp:24bits

sampling rate:48khz

adc/dc:24bits high-resolution chip

transmission delay：1.27ms

power：90-265 vac (50 / 60hz)

dimension：19"x1.75"x9"(483x44x229mm)

weight：10 lbs / 4.6 kg

threshold:-10 to 20dbu

compression ratio: 1:1 to 32:1

soft/hard turning point：0% to 100%

attack time: 5 to 200ms

release time: 0.1s to 3s

★signal input type

★peak limiter

analog/digital

threshold: -10 to 20dbu

attack time: 5 to 200ms

release time: 0.1s to 3s
