f24000d
★high pow er density: the f2400d delivers a total of 2x 4000w/4ohm in only 2u.
★ fineamp sound quality: f2400d amplifiers maintain excellent sound quality, with transparent
mid- and high-frequency performanceand new circuit designs, optimizedor sustained low-frequency output.
★ regulated switch mode power supply
★output power remains constant even with significant drops in the mains
voltage.
★ efficient cooling system
★ adjustable parameters
★ xlr input and link connectors
★ heavy- duty binding post or speakon output connectors
★ comprehensive protection and warning
4ch professional amplifier | f2400d | ||
★output power | ★connectors | ||
8ω stereo power | 4×1300w | input connectors | 3-pin xlr,electronically balanced |
4ωstereo power | 4×2000w | input impedance | 20kω balanced/10kω unbalanced |
output connectors | speakon connectors（neutrik） | ||
★technical specification | ★power | ||
frequency response | 20hz-20khz±0.875db | power requirement | 200-240v～50-60hz |
thd n(1khz,2000w 4ω)% | 0.82% | minimum voltage | 190-260v～47-63hz |
signal noise ratio(0db 8ω)) | 102db | ★dimension and weight | |
optional magnification(1khz 8ω) | 32db | dimension | 483×426.7×88mm |
weight | 15kg |
