f13000
★very high pow er and channel density: the four-channel f13000 delivers 4x 2200w/4ohm.
★ four- channel flexibility
four channels in one cabinet increases efficiency, flexibility and
value in powering monitor systems, line arrays, and bi- or tri-amped
systems.adjacent channels bridgeable for 2- or 3-channel
operation.
★ fineamp sound quality: f13000 amplifiers maintain the impeccable sonic performance
standards , with the same durability and even greater efficiency.
★ regulated switch mode pow er supply
output power remains constant even with significant drops in the
mains voltage.
★ adjustable parameters efficient cooling system
★ xlr input connectors
★ heavy- duty binding post or speakon output connectors
★ comprehensive protection and warning
4ch professional amplifier | f13000 | ||
★output power | ★connectors | ||
8ω stereo power | 4×1300w | input connectors | 3-pin xlr，electronically balanced |
4ω stereo power | 4×2200w | input impedance | 20kωbalanced/10ωunbalanced |
2ω stereo power | 4×2400w | output connectors | speakon connectors(neutrik) |
8ω bridged mono power | 2×4400w | ★power | |
4ω bridged mono power | 2×4800w | power requirement | 200-240v～50-60hz |
★technical specification | minimum voltage | 180-260v～50-60hz | |
frequency response | 20hz-25khz±0.5db | ★dimension and weight | |
thd n(rated power,4ω/khz)% | 0.1% | dimension | 483×377×88mm |
signal noise ratio(db) | 98db | weight | 13kg |
optional magnification | 23,26,29,32,35, 38,41,44db |
