bar

elastic bass

ktv

long throw rubber edge lf driver

near-field sound

rotatable 80x50°directivity horn

frequency respond

50 hz ~ 18 khz(± 3 db) ; 30 hz ~ 20 khz(- 10 db)

nominal coverage(- 6 db)

80° (h) 50° (v)  constant directivity

sensitivity(@1w/1m)

97 db spl

powerating(aes)

500w (continuous)   2000w (peak)

1000w ( recommended amplifier power)

nominal impedance

8ohm

maximum spl

123db (continuous)  129db (peak)

drivers

l f: 1x15″(75mm voice coil) rubber edge woofer

hf: 1x1.3″（44mm voice coil) compression driver

dimension( h x w x d)

681x 445 x 447mm

weight

26kg

speaker cables

1 1-

connectors

2 x nl4 mp neutrik speakon

materials

18mm multiply-plywood

finish

 black epoxy mesh grille acoustically reticulated foam
