pm12
application | feature |
bar | frequency response special design to avoid auditory fatigue |
theatre | rotatable and asymmetrical horn |
stage monitor | 13x m8 rigging points |
pole mount socket |
technical specification | |
frequency respond | 60 hz ~ 18 khz(±3 db) ; 50 hz ~ 20 khz(-10 db) |
nominal coverage(- 6 db) | 50°-100°（h）55°(v) constant direction |
sensitivity(@1w/1m) | 96 db spl |
powerating(aes) | 400 w |
nominal impedance | 8 ω |
maximum spl | 122 db (continuous) 128 db (peak) |
drivers | lf:1 x 12"（75 mm voice coil) woofer hf:1 x 44 mm voice coil compression driver |
physical data | |
dimension( h x w x d) | 576x372x384 mm |
weight | 23kg |
speaker cables | 1 1-（signal input & loop） |
connectors | 2 x nl4mp neutrik speakon connectors |
materials | 18 mm，24 mm birch plywood |
finish | black water paintings |
grille | porous steel mesh with black spraying |
